LED Fault indicator JYZ-HW

Overview

With the advancement of power detection and communication technology, as well as the development of big data, Four-Faith intelligent LED fault indicator can work under 3A current, perform fast fault detection within 20ms, and support power line clamping, through 3 different color LEDs The light change prompts the fault information, which is clear in the daytime of 100m and the night of 500m, which greatly shortens the time and scope of fault finding. LED Fault indicator is our unremitting pursuit to help you quickly restore the power supply.

Feature and Benefit

Color-changing LED lights to quickly identify different faults

20ms
Permanent fault, transient fault and low battery alarm can be distinguished and indicated by 3 different super bright flashing LEDs respectively. And a ground fault can be indicated by two alternately different super bright flashing LEDs. The fastest fault detection time can reach 20ms
Online energy harvesting, long service life

up to 10 years
The JYZ-HW indicator can be powered online through the built-in current sensor. LED Fault indicator only needs a line load of more than 3A to start, and the service life can reach 10 years.
Ultra-high detection accuracy, reducing fault errors

±1%
300A~800A
Four-Faith's own intelligent algorithm and special current sensor, the current detection accuracy of JYZ-HW fault indicator can reach ±1% in the load line of 300~800A, which helps to accurately judge the occurrence of fault
Simplified deployment, lower installation costs

Hot Stick Mount
Using the indicator adapter with the hot stick installation, it supports the installation of the indicator without power failure. The unique design supports the installation directly on the ground.

Technical Parameter

Parameter	Value
Short-circuit Trip Current (Phase to Phase)	50~1200A adjustable, 1A step, 150A default
Earth-fault Voltage Drop (Phase to Ground)	Adjustable: 1% step, 30% default
Earth-fault Response Delay	Adjustable: 1 second step, 30s default
Permanent fault	Indication of permanent fault by three red ultra-bright blinking LEDs.
Transient failure	Indication of instantaneous fault by three green ultra-bright blinking LEDs
Earth-fault	Indication of earth-fault by red and green ultra-bright LEDs blinking alternately.
Low battery warning	Indication of Low battery alarm by three yellow ultra-bright blinking LEDs
Indication Unit Reset	1. manual by magnet. 2. remote reset through SCADA system 3. time reset: adjustable, 1 second step, 24h default, max. 48h 4. Auto delay reset after repower, 1 second step, 30s default max 5min, only for permanent fault
Protection Class	IP68
Internal Type Test	According to IEEE495-2007
Operation Temperature Range	-40~+70℃
Power Supply	Lithium battery type AA 3.6V / 9Ah, replaceable
Battery Life	10 years
Accuracy	0A~300A ±3A 300A~800A ±1%
Cable Diameter Ranges	6mm~42mm
Blinking Frequency	10 per minute, adjustable
Voltage range	5~38KV
Current withstand	31.5KA/4s
Communication	433MHz from indicators to DCU
